Metaco has developed Roller Blind component parts since 1973 and has accumulated its know-how & technology.
As the result, Metaco can offer various types of component parts to meet each customer's demand.
Metaco can supply very functional and unique component part to enjoy satisfied performance.
Roller Tube
Diameter : 40mm,48mm,60mm,80mm,100mm,130mm,160mm
Spring Motor (Spring Operation)
7 types for MRS40
is available to cover a wide range of Roller Blind size.
Spring Booster (Hand Operation)
7 types for MRS40
8 types for MRS60/80
is available to cover a wide range of Roller Blind size.
Limit Brake
Speed Deceralation for Spring Operation
To control screen rising speed.
Pre-Set upper stop position
Rising screen stops at the same upper stop position every time and adjusts it easily.
Reduction Gear
1 : 1 and 1 : 5 Gear Ratio for MRS40
1 : 3.74 and 1 : 14 Gear Ratio for MRS60/80
is available to get light and smooth chain operation.
Bracket
Joint Bracket for MRS40 and MRS60/80
Angle Bracket for MRS60/80
is available to link several Roller Blinds with one operation.
Spring Drive
System |
MRS40 |
Category |
Medium Duty |
Roller Tube Diameter
* Aluminum Extrusion |
40mm |
Max Blind Size: Width/Height |
W:3000mm / H:3000mm |
Suitable Screen Weight: |
by 400g/㎡ |
Speed Control Device |
yes |
Spring Motor type |
7 types |
Component Part Color |
White
Ivory |
Hand Drive
System |
MRS40 |
MRS60 |
MRS80 |
Category |
Medium Duty |
Heavy Duty |
Heavy Duty |
Roller Tube Diameter
* Aluminum Extrusion |
40mm |
60mm |
80mm |
Max Blind Size: Width/Height |
W:3000mm / H:4000mm |
W:3600mm / H:5000mm |
W:4000mm / H:5000mm |
Suitable Screen Weight: |
by 400g/㎡ |
over 600g /㎡ |
over 600g /㎡ |
Reduction Gear Ratio |
1 : 1
1 : 5 |
1 : 3.74
1 : 14 |
1 : 3.74
1 : 14 |
Spring Booster type |
7 types |
1 : 3.74
1 : 14 |
8 types |
Unique Bracket system |
Joint Bracket |
Joint Bracket
Angle Bracket |
Joint Bracket
Angle Bracket |
Component Part Color |
Ivory
Black |
Silver
Silver |
Silver
Silver |
